Product List
Allen-Bradley

 PanelView HMI



Electronic Operator Interface
Graphic Terminals



Model Description
 2711C-F2M    C200    Function keys    2 in.    Monochrome
 2711C-K2M      Numeric and function keys
 2711C-T3M    C300    Touch screen    3 in.
 2711C-K3M      Numeric and function keys
 2711C-T6M    C600    Touch screen    6 in.    Monochrome
 2711C-T6C          Color STN
 2711C-T6T          Color TFT
 2711C-T10C    C1000    Touch screen    10 in.    Color STN

Cables for PanelView Component Terminals

Model Description
 2711C-CBL-UU02    USB-A host to USB-B device cable, 2 m (6.56 ft)    C200, C300, C600, C1000
 2711P-CBL-EX04    Ethernet crossover CAT5 cable 4.3 m (14 ft)    C600, C1000
 2711C-RCSD    USB to SD adapter with secure digital (SD) card    C200, C300, C600, C1000
 1747-CP3    Serial 9-pin D-shell to 9-pin D-shell null modem cable    C200, C300, C600, C1000
 1761-CBL-PM02    Serial 9-pin D-shell to 8-pin mini DIN cable, 2 m (6.56 ft)    C200, C300, C600, C1000
 2711C-CBL-AB03    RS-485 5-pin to RJ45 cable    C200, C300, C600, C1000



PanelView Plus™ Operator Terminals


The PanelView Plus Compact terminals feature:




5.5-inch Grayscale Display Keypad Touch Keypad/Touch
RS-232 Communication Only, DC Input 2711P-K6M5D 2711P-T6M5D 2711P-B6M5D
RS-232 Communication Only, AC Input 2711P-K6M5A 2711P-T6M5A 2711P-B6M5A
Ethernet, RS-232 and Modular Communication Interface, DC Input 2711P-K6M20D 2711P-T6M20D 2711P-B6M20D
Ethernet, RS-232 and Modular Communication Interface, AC Input 2711P-K6M20A 2711P-T6M20A 2711P-B6M20A
Description Model
5.5-inch Color TFT Display Keypad Touch Keypad/Touch
RS-232 Communication Only, DC Input 2711P-K6C5D 2711P-T6C5D 2711P-B6C5D
RS-232 Communication Only, AC Input 2711P-K6C5A 2711P-T6C5A 2711P-B6C5A
Ethernet, RS-232 and Modular Communication Interface, DC Input 2711P-K6C20D 2711P-T6C20D 2711P-B6C20D
Ethernet, RS-232 and Modular Communication Interface, AC Input 2711P-K6C20A 2711P-T6C20A 2711P-B6C20A

PanelView Plus CE Operator Terminals
(Bulletin 2711P)



Description Model
10.4-inch TFT Display Keypad Touch Key/Touch Keypad Touch Key/Touch
Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM 2711P-K10C4D1 2711P-T10C4D1 2711P-B10C4D1 — — —
Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM ¬  2711P-K10C4D2 2711P-T10C4D2 2711P-B10C4D2 2711P-K10C4D6 2711P-T10C4D6 2711P-B10C4D6
Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM ¬  — — — 2711P-K10C4D7 2711P-T10C4D7 2711P-B10C4D7
Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM 2711P-K10C4A1 2711P-T10C4A1 2711P-B10C4A1 — — —
Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM ¬  2711P-K10C4A2 2711P-T10C4A2 2711P-B10C4A2 2711P-K10C4A6 2711P-T10C4A6 2711P-B10C4A6
Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM ¬  — — — 2711P-K10C4A7 2711P-T10C4A7 2711P-B10C






PanelView Plus 600 Grayscale

Description Model
5.5-inch Grayscale Display Keypad Touch Keypad/Touch
RS-232 Communication Only, DC Input 2711P-K6M5D 2711P-T6M5D 2711P-B6M5D
RS-232 Communication Only, AC Input 2711P-K6M5A 2711P-T6M5A 2711P-B6M5A
Ethernet, RS-232 and Modular Communication Interface, DC Input 2711P-K6M20D 2711P-T6M20D 2711P-B6M20D
Ethernet, RS-232 and Modular Communication Interface, AC Input 2711P-K6M20A 2711P-T6M20A 2711P-B6M20A

Ordering
PanelView Plus 600 Grayscale
5.5-inch Grayscale Display
Keypad
2711P-K6M5D RS-232 Communication Only, DC Input
2711P-K6M5A RS-232 Communication Only, AC Input
2711P-K6M20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-K6M20A Ethernet, RS-232 and Modular Communication Interface, AC Input
Touch
2711P-T6M5D RS-232 Communication Only, DC Input
2711P-T6M5A RS-232 Communication Only, AC Input
2711P-T6M20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-T6M20A Ethernet, RS-232 and Modular Communication Interface, AC Input
Keypad/Touch
2711P-B6M5D RS-232 Communication Only, DC Input
2711P-B6M5A RS-232 Communication Only, AC Input
2711P-B6M20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-B6M20A Ethernet, RS-232 and Modular Communication Interface, AC Input
PanelView Plus 600 Color
5.5-inch Color TFT Display
Keypad
2711P-K6C5D RS-232 Communication Only, DC Input
2711P-K6C5A RS-232 Communication Only, AC Input
2711P-K6C20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-K6C20A Ethernet, RS-232 and Modular Communication Interface, AC Input
Touch
2711P-T6C5D RS-232 Communication Only, DC Input
2711P-T6C5A RS-232 Communication Only, AC Input
2711P-T6C20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-T6C20A Ethernet, RS-232 and Modular Communication Interface, AC Input
Keypad/Touch
2711P-B6C5D RS-232 Communication Only, DC Input
2711P-B6C5A RS-232 Communication Only, AC Input
2711P-B6C20D Ethernet, RS-232 and Modular Communication Interface, DC Input
2711P-B6C20A Ethernet, RS-232 and Modular Communication Interface, AC Input
PanelView Plus 700-1500
6.5-inch TFT Display
Keypad
2711P-K7C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-K7C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K7C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-K7C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Touch
2711P-T7C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-T7C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T7C4D2K Conformal-Coated, Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T7C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-T7C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Key/Touch
2711P-B7C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-B7C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B7C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-B7C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Keypad
2711P-K7C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K7C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-K7C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-K7C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Touch
2711P-T7C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T7C4D6K Conformal-Coated, Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T7C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-T7C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-T7C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
PanelView Plus and PanelView Plus CE 1000 Color
10.4-inch TFT Display
Keypad
2711P-K10C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-K10C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K10C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-K10C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Touch
2711P-T10C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-T10C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T10C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-T10C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Key/Touch
2711P-B10C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-B10C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B10C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-B10C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Keypad
2711P-K10C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K10C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-K10C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-K10C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Touch
2711P-T10C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T10C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-T10C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-T10C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
PanelView Plus and PanelView Plus CE 1250 Color
12.1-inch TFT Display
Keypad
2711P-K12C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-K12C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K12C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-K12C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Touch
2711P-T12C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-T12C4D2K Conformal-Coated, Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T12C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T12C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-T12C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Key/Touch
2711P-B12C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-B12C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B12C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-B12C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Keypad
2711P-K12C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K12C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-K12C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-K12C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Touch
2711P-T12C4D6K Conformal-Coated, Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T12C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T12C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-T12C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-T12C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Key/Touch
2711P-B12C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B12C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-B12C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-B12C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
PanelView Plus and PanelView Plus CE 1500 Color
15-inch TFT Display
Keypad
2711P-K15C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-K15C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K15C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-K15C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Touch
2711P-T15C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-T15C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T15C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-T15C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Key/Touch
2711P-B15C4D1 Standard Communication (Ethernet and RS-232), DC Input, 64 MB Flash/RAM
2711P-B15C4D2 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B15C4A1 Standard Communication (Ethernet and RS-232), AC Input, 64 MB Flash/RAM
2711P-B15C4A2 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
Keypad
2711P-K15C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-K15C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-K15C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-K15C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Touch
2711P-T15C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-T15C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-T15C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-T15C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
Key/Touch
2711P-B15C4D6 Standard Communication (Ethernet and RS-232), DC Input, 128 MB Flash/RAM
2711P-B15C4D7 Standard Communication (Ethernet and RS-232), DC Input, 256 MB Flash/RAM
2711P-B15C4A6 Standard Communication (Ethernet and RS-232), AC Input, 128 MB Flash/RAM
2711P-B15C4A7 Standard Communication (Ethernet and RS-232), AC Input, 256 MB Flash/RAM
 Communication Interface Devices
RS-232 Isolated 2711P-RN22C
DH-485 2711P-RN3
DH-485 2711P-RN6
DH+ 2711P-RN8
ControlNet 2711P-RN15C
  2711P-RN15S

Tel: 86-510-85572185
Fax: 86-510-85884818
Copyright © 2012 Wuxi dekong Co.,Ltd . All rights reserved.
