| Ordering |
| CPU |
| 1769-L23-QBFC1B |
512 Kb 16 DI/16DO/4AI/2AO/4hsc |
| 1769-L23E-QBFC1B |
512 kB 1 EtherNet/IP port 16 DC inputs 16 DC outputs 4 high-speed counters |
| 1769-L23E-QB1B |
512 kB 1 EtherNet/IP port 16 DC inputs 16 DC outputs |
| 1769-L31 |
512 kB 2 RS-232 ports (isolated DF1 or ASCII; non-isolated DF1 only) |
| 1769-L32C |
750 kB 1 ControlNet port 1 RS-232 serial port (DF1 or ASCII) |
| 1769-L32E |
750 kB 1 EtherNet/IP port: (DF1 or ASCII) 1 RS-232 port (DF1 or ASCII) |
| 1769-L35CR |
1.5 MB 1 RS-232 serial port (DF1 or ASCII) 1 redundant ControlNet port |
| 1769-L35E |
1.5 MB 1 EtherNet/IP port: (DF1 or ASCII) 1 RS-232 port (DF1 or ASCII) |
| 1768-L43 |
2 MB ,RS 232 1 PORT |
| 1768-L45 |
3 MB ,RS 232 1 PORT |
| Expansion I/O |
| 1769-IA8I |
8 individually isolated inputs 100/120V AC |
| 1769-IA16 |
16 inputs 100/120V AC |
| 1769-IM12 |
12 inputs 200/240V AC |
| 1769-OA8 |
8 outputs 100/240V AC |
| 1769-OA16 |
16 outputs 100/240V AC |
| 1769-IG16 |
16 inputs 5V DC TTL signal input |
| 1769-IQ16 |
16 inputs 24V DC, sinking or sourcing |
| 1769-IQ16F |
16 high-speed inputs 24V DC, sinking or sourcing |
| 1769-IQ32 |
32 inputs 24V DC, sinking or sourcing |
| 1769-IQ32T |
32 inputs 24V DC, sinking or sourcing |
| 1769-IQ6XOW4 |
6 inputs 24V DC, sinking or sourcing |
| 4 outputs AC/DC normally open relay contact outputs |
| 1769-OB8 |
8 outputs 24V DC, sourcing |
| 1769-OB16 |
16 outputs 24V DC, sourcing |
| 1769-OB16P |
16 outputs, protected 24V DC, sourcing |
| 1769-OB32 |
32 outputs 24V DC, sourcing |
| 1769-OB32T |
32 outputs 24V DC, sourcing |
| 1769-OG16 |
16 outputs 5V DC TTL signal output |
| 1769-OV16 |
16 outputs 24V DC, sinking |
| 1769-OV32T |
32 outputs 24V DC, sinking |
| 1769-OW8 |
8 outputs |
| 1769-OW8I |
8 outputs, individually isolated |
| 1769-OW16 |
16 outputs |
| 1769-IF4 |
4 inputs, differential or single-ended 0…20 mA, 4…20 mA |
| 1769-IF4I |
4 inputs, differential or single-ended, individually isolated 4…20 mA |
| 1769-IF8 |
8 inputs, differential or single-ended 0…20 mA, 4…20 mA |
| 1769-IF16C |
16 inputs, single-ended 0…20 mA, 4…20 mA |
| 1769-IF16V |
16 inputs, differential 0…10V |
| 1769-IF4XOF2 |
4 differential or single-ended inputs 0…20 mA |
| 2 single-ended outputs 0…10V DC |
| 1769-IF4FXOF2F |
4 high-speed differential or single-ended inputs 0…20 mA, 4…20 mA |
| 2 high-speed single-ended outputs 0…10V |
| 1769-OF2 |
2 outputs, single-ended 0…20 mA, 4…20 mA |
| 1769-OF4 |
4 outputs, single-ended 0…20 mA, 4…20 mA |
| 1769-OF4CI |
4 outputs, differential, individually isolated 0…20 mA, 4…20 mA |
| 1769-OF4VI |
4 outputs, differential, individually isolated 0…10V |
| 1769-OF8C |
8 outputs, single-ended 0…20 mA, 4…20 mA |
| 1769-OF8V |
8 outputs, single-ended 0…10V |
| 1769-IR6 |
6 RTD inputs |
| 1769-IT6 |
6 thermocouple inputs Thermocouple types B, C, E, J, K, N, R, S, T |
| Communication Interface Devices |
| 1768-ENBT |
1768 EtherNet/IP communication bridge module |
| 1768-EWEB |
1768 Ethernet web server module |
| 1768-CNB |
1768 CompactLogix ControlNet communication bridge module, single media |
| 1768-CNBR |
1768 CompactLogix ControlNet communication bridge module, redundant media |
| 1769-SDN |
CompactLogix DeviceNet Scanner Module |
| 1769-ADN |
CompactLogix DeviceNet Adapter Module |
| 1747-CP3 |
9-pin D-shell, straight to 9-pin D-shell, right angle |
| 1761-CBL-AC00 |
9-pin D-shell, right angle to 9-pin D-shell, right angle |
| 1761-CBL-AP00 |
9-pin D-shell, right angle to 8-pin mini-DIN |
| 1761-CBL-PM02 |
9-pin D-shell, straight to 8-pin mini-DIN |
| 1761-NET-AIC |
Advanced Interface Converter (AIC+) connects each channel on the 1756-DH485 module to the DH-485 network |
| 9300-RADKIT |
Remote access dial-in kit |
| 1769-CRLx |
Right to left |
| 1769-CRRx |
Right to right |
| 1769-CRLx |
Right to left |
| 1769CRRx |
Right to right |
| 1769-CLLx |
Left to left |
| 1768-PA3 |
CompactLogix Dual Voltage Input Power Supply 85…265V AC or 108…132V DC 24V DC |
| 1768-PB3 |
CompactLogix 24V DC Input Power Supply 16.8…31.2V DC |
| 1769-PA2 |
Compact 120/220V AC Expansion Power Supply |
| 1769-PB2 |
Compact 24V DC Expansion Power Supply |
| 1769-PA4 |
Compact 120/220V AC Expansion Power Supply |
| 1769-PB4 |
Compact 24V DC Expansion Power Supply |
| 1769-ECR |
Right end cap |
| 1769-EC |
Left end cap |
| 1764-RTC |
MicroLogix 1500 Real-Time Clock Module |
| 1764-MM1 |
MicroLogix 1500 8 KB Memory Module |
| 1764-MM1RTC |
MicroLogix 1500 8 KB Memory Module with Real-Time Clock |
| 1764-MM2¬ |
MicroLogix 1500 16 KB Memory Module |
| 1764-MM2RTC |
MicroLogix 1500 16 KB Memory Module with Real-Time Clock |
| 1764-MM3T |
MicroLogix 1500 16 KB Memory Module with recipe data storage |
| 1764-MM3RTCT |
MicroLogix 1500 16 KB Memory Module with recipe data storage and Real-Time Clock |
| 1784-CF64 |
64 MB Memory |
| 1784-CF128 |
128 MB Memory |
| 1769-BA |
Lithium battery |
